EASA Certified 8.33 Radios and Mode S Transponders at low prices
After a number of requests, we are now selling 8.33 EASA Certified Transceivers and Mode S Transponders.
We are able to provide very interesting prices with the low VAT that we have in Andorra - this saves you more than 15% in general compared to other European countries (the VAT in Andorra is just 4,5%).
On top of that we can offer even better prices on selected models.
f.u.n.k.e. Avionics
VHF Voice Radios
Note: From 1 January 2018 an operator shall not operate an aircraft in European airspace where carriage of radio is required unless the aircraft radio equipment has the 8,33 kHz channel spacing capability (see Commission Implementing Regulation (EU) No 1079/2012 of 16 November 2012).
The ATR833 is a complete solution for radios in small aircraft with the new channel separation of 8.33 kHz. The channel spacing can be switched between 25kHz and 8,33kHz. The built-in vox controlled intercom operates up to 4 microphones (2 standard, 2 dynamic). In many cases no extra intercom is required. This saves cost and weight. All headsets are separately adjustable. Using similar headsets a 4-place intercom can be built-up.
In addition to the standard functions there are 2 memories available. The user can define up to 100 named frequencies to build up their own database. In addition the last 10 frequencies used can be recalled. The ATR833 is available either with OLED or LCD display.
ATR833-2K-OLED - VHF 8.33 radio - dual watch, 4 mic intercom, best readability, German quality, delivered with EASA Form 1
FUNKE ATR833-2K-OLED Price: 1.500,- Euro incl. VAT (delivered in Andorra) Order here.
Download ATR833-2K-OLED brochure (english)
ATR833-2K-LCD - VHF 8.33 radio - dual watch, 4 mic intercom, best price, German quality, delivered with EASA Form 1
FUNKE ATR833-2K-LCD Price: 1.450,- Euro incl. VAT (delivered in Andorra) Order here.
Download ATR833-2K-LCD Brochure (english)
NEW f.u.n.k.e. ATR833S Radio
The ATR833S replaces the well-known ATR500 radio. It complies with the new channel separation of 8.33 kHz. The ATR833S is a completely new development with state-of-the-art digital signal processing. The extremely lightweight plastic housing reduces the weight to below 400 grams and makes it one of the lightest radios in its class.
The ATR833S has like the well-known ATR833 a built-in voice controlled intercom. New is the automatic recognition of the microphone type.
The simple and intuitive operation will appeal to pilots, who appreciate the essence of easy operation and makes it particularly interesting for clubs and aircraft owner communities.
The bright two-line LCD display of theATR500 was deliberately chosen, as it is easy to read with just a few additional icons providing all essential information.
For the radio, a large number of cable adapters are available, so that in most cases an easy replacement of the device is possible.
FUNKE ATR833S Price: 1.275,- Euro incl. VAT (delivered in Andorra) Order here.
Download ATR833S Brochure (english)
The funke 8.33 Radio also exists in 160mm format (ATR833A-II-OLED).
Mode-S Transponders
Our Mode-S Transponder product family TRT800 is well placed on the market for General Aviation. The new Mode-S standard (mandated in Germany since 01.04.2008 for all aircraft flying above 5000 ft sea level or at more than 3500 ft height above terrain) covers further information besides the ICAO-Code and offers the possibility to broadcast GPS based position data as well. Several thousands of TRT800 transponders have been installed in General Aviation aircraft in Europe in the meantime.
The TRT800H is a standard transponder for all applications in general aviation from ultralight aircraft to gliders and piston engine aircraft. It offers the classical A/C modes of operation plus full Mode-S support including the future-oriented extended squitter function. It can be delivered either with OLED or LCD display.
TRT800H-OLED - Transponder Mode A/C/S, class 1, OLED display, German quality, delivered with EASA Form 1
TRT800H-OLED Price: 2360,- Euro incl. VAT (delivered in Andorra) Order here.
Download TRT800H OLED Brochure (english)
The f.u.n.k.e. Mode-S Transponder also exists with LCD Display (TRT800H-LCD) and in 160mm format (TRT800A-OLED).
Please Contact us if you have any questions.
We can deliver all f.u.n.k.e. Transceivers and Transponders and accessories at low prices.
